Benefits
› Versatile designs
› High quality construction
› Simplified installation with less onsite labor
Optimized pump systems for chilled & condenser water loops
Directly Interface with the Chiller built-in plant manager. Single point responsibility for Chiller + Controls + Pumps Backed up by Daikin Warranty and Service Network.
BENEFITS
1. Single electrical connection
2. Simplified installation, startup and commisioning.
3. Compact footprint
4. Integrated control & Instrumentation
5. Fully adaptable to your application
STANDARD DESIGN INCLUDES:
1.Base mounted, end suction pumps
2. Daikin Intelligent Pump Manager Controller
3. Suction Diffusers
4. Triple duty valves
5. Manual Gauges
6. Pump common discharge header
7. Pump common suction header
8. Lifting lugs
TECHNICAL DATA
All Daikin skids are assembled on a steel base with or without enclosure. They arrive on site pre-wired, pre-piped and pre-commissioned, eliminating the scheduling challenges and cost overruns of a site-built system.
| System Conditions | Range |
| System head (bars) | 3 to 6 |
| System flow rate (Ips) | up to 380 |
| Number of pumps | 2 to 5 |
| Motor power (kW) | 10 to 200 |
| Optional Components |
| Vertical inline or split case pumps |
| Variable frequency drives (VFD) |
| Power distribution |
| Intelligent Pump Manager & instrumentation |
| Air separator |
| Pressurization Unit |
| Expansion tank |
| Suction diffusers |
| Check valves |
| Chemical pot feeder |
| Glycol feeder |
| Buffer tank |
| Plate Heat Exchanger |
| Inertia Base |
| Insulation |
| Cladding |
Standard Pump Skid
Pump skid with / Optional components options
SKID DIMENSIONS
*Dimensions shown for standard skid systems
- 2-Pump Systems
- 3-Pump Systems
- 4-Pump Systems
| Header Size (mm) | L (m) | W (m) | H (m) |
| 150 | 2.1 | 2.6 | 2.3 |
| 200 | 2.1 | 2.6 | 2.3 |
| 250 | 2.5 | 2.7 | 2.5 |
| 300 | 2.5 | 3.3 | 2.5 |
| Header Size (mm) | L (m) | W (m) | H (m) |
| 200 | 3 | 2.6 | 2.3 |
| 250 | 3.5 | 2.6 | 2.3 |
| 300 | 3.7 | 2.7 | 2.5 |
| 350 | 3.7 | 2.7 | 2.5 |
| 400 | 3.7 | 3.3 | 2.5 |
| Header Size (mm) | L (m) | W (m) | H (m) |
| 250 | 4 | 2.6 | 2.3 |
| 300 | 4.5 | 2.6 | 2.3 |
| 350 | 4.5 | 2.6 | 2.3 |
| 400 | 4.9 | 2.7 | 2.5 |
| 450 | 4.9 | 3.3 | 2.5 |
